Trek Dual Sport 3 Gen 4

Trek Dual Sport 3 Gen 4
  • Color: Rage Red
  • Color: Matte Trek Black
  • Color: Dark Aquatic
This item is currently not available.

Details

Dual Sport 3 is a high-performance hybrid bike with upgraded components that stand up to long rides on a variety of surfaces, from city streets to gravel trails and more! Plus, front suspension, a wide-range 1x drivetrain, tubeless-ready rims, and puncture-resistant tires give you the confidence to take on bigger adventures.

It's right for you if...
You want to up the adventure level on your recreational rides, and want a fast and rugged hybrid bike with quality parts that will withstand daily commutes, fitness rides on light trails, rail trail tours, and more.

The tech you get
A lightweight aluminum frame, a suspension fork with a lockout feature, and a simple 1x10 Shimano drivetrain that ditches the front derailleur for easier operation. Don't worry, the wide-range 11-46 cassette still gives you all the gears you need to conquer hills and crush flats. Shimano hydraulic disc brakes, tubeless-ready rims, puncture-resistant all-terrain tires, ergonomic grips, and a Blendr stem for easy accessory integration.

The final word
Dual Sport 3 is fast and efficient on pavement and confident and capable on dirt trails. It has upgrades on the parts that make the biggest difference in performance, like the simpler, lighter-weight Shimano 1x drivetrain, tubeless-ready rims, and puncture-resistant tires.

Why you'll love it
- The 1x drivetrain gives you all the gears you need and none you don’t
- The fork's hydraulic lockout feature ensures you're always riding efficiently: close it for smooth pavement, open it up on rougher trails
- A wide range of gearing means you never have to pedal too hard or too soft, even on the biggest hills
- It's easy to accessorize with racks, a kickstand, fenders, lights, and fitness devices to track your ride data when you add DuoTrap S
- Internal cable routing extends the life of your cables and adds to the bike's sleek look

Geometry

Sizes:
All measurements provided in cm unless otherwise noted.
Frame size letterSmallMediumLargeX-Large
Wheel size 700c 700c 700c 700c
A- Seat tube 38.1 44.5 50.8 57.1
B- Seat tube angle 74.5° 74.0° 73.5° 72.5°
C- Head tube length 11.5 12.5 13.5 15.5
D- Head angle 70.0° 71.0° 71.0° 72.0°
E- Effective top tube 57.5 59 60.5 63.5
F- Bottom bracket height 29.4 29.4 29.4 29.4
G- Bottom bracket drop 6 6 6 6
H- Chainstay length 46 46 46 46
I- Offset 3.8 3.8 3.8 3.8
J- Trail 8.5 8.2 8.2 7.5
K- Wheelbase 109.6 110 110.5 111
L- Standover 66.7 76.5 80.8 85
M- Frame reach 41 41.6 42.3 43.4
N- Frame stack 59.5 60.6 61.6 63.9

Smaller frames (S) have a top tube that dips down as it approaches the seat tube. This design makes for a lower standover height, which is good for shorter riders because it allows them to straddle their bike more easily. Larger frames (M and up) have a straight top tube because taller riders with longer legs typically don’t have the same issues with standover height.

Specs

Frame Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR
Fork SR Suntour NEX, coil spring, preload, hydraulic lockout, 100x5mm QR, 63mm travel
Rims Bontrager Tubeless Ready Disc, 32-hole, Presta valve
Spokes 14g stainless steel
Tires Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40c
Crankset Size: S, M Prowheel alloy, 40T narrow-wide ring, 170mm length
Size: L, XL Prowheel alloy, 40T narrow-wide ring, 175mm length
Shifters Shimano Deore M4100, 10 speed
Rear Derailleur Shimano Deore M5120, long cage
Cassette/Freewheel Shimano Deore M4100, 11-46T, 10 speed
Chain KMC X10, 10 speed
Brakes Shimano MT200 hydraulic disc
Handlebars Size: S, M Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 600mm width
Size: L, XL Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 660mm width
Tape/Grips Bontrager XR Endurance Elite, lock-on, ergonomic
Stem Size: S Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: M, L Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
Size: XL Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 110mm length
Headset 1-1/8" threadless, sealed cartridge bearings
Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length
Saddle Bontrager H1
Pedals Wellgo M141, resin body, alloy cage

* Subject to change without notice.

Part Numbers

Option UPC MPN
Rage Red / Small 601842580790 5260108
Rage Red / Medium 601842580783 5260109
Rage Red / Large 601842580769 5260111
Rage Red / X-Large 601842580745 5260113
Matte Trek Black / Small 601842580837 5260104
Matte Trek Black / Medium 601842580820 5260105
Matte Trek Black / Large 601842580813 5260106
Matte Trek Black / X-Large 601842580806 5260107
Dark Aquatic / Small 601842580721 5260115
Dark Aquatic / Medium 601842580714 5260116
Dark Aquatic / Large 601842580691 5260118
Dark Aquatic / X-Large 601842580677 5260120
